WALDOCH CONVERISON VAN SMART BATTERY CONVERTER CHARGING SYSTEM WITH QUICK CONNECT GALAXY LANDMARK TAILGATING SYSTEM POWERS THE FULL CONVERSION WITHOUT THE KEYS

Smart RV Power Converter Kit combines a Go Power! 75 Amp Smart Battery Converter/Charger with a dedicated wire harness for a complete, plug-and-play 12-volt power solution for your RV.

Designed for flooded lead acid and AGM batteries, the Go Power! GPC-75-MAX converts 120V AC (105–135V AC nominal input) to 13.6V DC and delivers up to 75 amps and 1,095W of continuous power. Using advanced switch-mode technology, it can either fast-charge your deep-cycle battery bank or directly power your 12-volt loads whenever you are connected to shore power.

As a power supply, its tightly controlled regulation allows you to operate any 12V DC load up to the converter’s rated output current. As a battery charger, it provides full-rated current when battery capacity is low, then transitions into float charging as the battery nears full capacity to prevent self-discharge and help extend battery life.

The included wire harness connects to the exterior power plug, providing a clean, secure pathway for shore power into your RV electrical system. This makes installation straightforward for new builds, upgrades, or replacements, giving you a compact, lightweight, and reliable 12V power solution.

Features:

• Designed for flooded lead acid and AGM batteries
• Converts 120V AC (105–135V AC input) to 13.6V DC
• 75A DC output, 1,095W continuous converter output
• Operates as a regulated 12V DC power supply for loads up to rated output current
• Maintains and charges a single battery bank with full-rated output when battery is low
• Float charging reduces self-discharge and helps extend battery life
• 4-stage charging: Bulk, Absorption, Float, Equalization
• Multiple protection features for long, trouble-free service:
  • Reverse battery polarity protection
  • Over-current protection with cycle-by-cycle peak limiting and rated current limiting
  • Over-temperature and brown-out input protection
• Compact and lightweight design for easy integration in RV power systems
• Included wire harness provides a plug-and-play connection from exterior power plug to RV electrical system

Specifications:
Model: GPC-75-MAX
Battery Banks: 1
DC Output Amperage: 75A
DC Output Voltage: 13.6V DC
AC Input Voltage: 105–135V AC
Converter Output: 1,095W continuous
Frequency: 47–63 Hz
Dimensions (H x W x L): 3.45" x 7.5" x 10.5"
